Hop Trike
HOP TRIKES Rehabilitation Tricycles, developed and manufactured by LIW Care Technology, are intended for physical rehabilitation, driving and transport of disabled people and the elderly.
HOP TRIKES Rehabilitation Tricycles, developed and manufactured by LIW Care Technology, are intended for physical rehabilitation, driving and transport of disabled people and the elderly. Intended for people whose illnesses prevent independent movement on a regular two-wheeled bicycle. Bikes help to increase muscle strength and support fitness, as well as enjoy physical activity outdoors on any type of paved surface. Thanks to the two wheels at the rear of the bike, using the device does not require the sense of balance and body balancing to maintain the balance necessary for riding.
LN Parameter Unit Symbol HOP.16 HOP.20 HOP.24 HOP.26
1 Saddle height cm SH 64÷75 74÷87,5 84÷95 90÷100
2 Saddle depth cm SD 25 25 25 25
3 Saddle width cm SW 25 25 25 25
4 Back angle ° BA 85°÷100° 85°÷100° 85°÷100° 85°÷100°
5 Back height cm BH 30÷55 30÷55 30÷55 30÷55
6 Height of the side supports cm LH 16÷40 16÷40 16÷40 16÷40
7 Width of the side supports cm LW 20÷36 20÷36 20÷36 20÷36
8 Distance from the saddle to the pedal in the
lower position
cm PH 58÷72 68÷78 72÷83 76÷86,5
9 Bottom bracket height cm KH 21 26 30 30
10 Wheelbase cm AL 83 104,5 120 123
11 Saddle to headset distance cm LS 39 47 53 58
12 Length cm L 124 155 181 190
13 Width cm W 67,5 67,5 75 75
14 Height cm H 67,5 89,5 98,5 103,5
15 Rear wheel diameter cm DR 40,7 50,8 61 66
16 Front wheel diameter cm DF 40,7 50,8 61 66
17 Maximum patient weight kg 40 60 80 100
18 Maximum total weight kg 150 150 150 150
